Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop

Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
rixson9336630
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
rixson9336630
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
Picture of Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop
naxt
prev

Product Details

Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop

Best Suited For Heavy Duty Surface And Stop For High Traffic Interior And Exterior Doors.

Door Opening Size:

Butts Offset Pivots: 43-1/16 - 48

Center Hung Pivots: 46-1/16 - 50

Product Description & Features

Heavy-duty Interior or exterior doors

Doors are single acting Non-handed

Slide track design

Recommended for high traffic, heavy abuse installations

Heavy shock absorber spring provides 5-7compression before deadstop

Complete screw packet with thru-bolts for door, wood and machine screws for frame

Standard architectural finishes

Durable slider cam and shock block

110 maximum opening 1-3/4" minimum door thickness1-3/16" square channel

Stop function UL listed for fire door assemblies

Model: Norton Rixson  9-536 630,  9-536-630,  9 536 630,  9536630

Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop

SKU: 9-536

In Stock

$412.96

Finish *

689 - Silver Aluminum Painted
689 - Silver Aluminum Painted
630 - Satin Stainless Steel
630 - Satin Stainless Steel
690 - Dark Bronze Painted
690 - Dark Bronze Painted
696 - Satin Brass Painted
696 - Satin Brass Painted
BSP - Black Suede Powder Coat
BSP - Black Suede Powder Coat

About this item

Norton Rixson Checkmate 9-536 Surface Mount Overhead Stop

Best Suited For Heavy Duty Surface And Stop For High Traffic Interior And Exterior Doors.

Door Opening Size:

Butts Offset Pivots: 43-1/16 - 48

Center Hung Pivots: 46-1/16 - 50

Product Description & Features

Heavy-duty Interior or exterior doors

Doors are single acting Non-handed

Slide track design

Recommended for high traffic, heavy abuse installations

Heavy shock absorber spring provides 5-7compression before deadstop

Complete screw packet with thru-bolts for door, wood and machine screws for frame

Standard architectural finishes

Durable slider cam and shock block

110 maximum opening 1-3/4" minimum door thickness1-3/16" square channel

Stop function UL listed for fire door assemblies

Model: Norton Rixson  9-536 630,  9-536-630,  9 536 630,  9536630
