Rockwood K1050-10x34-US3 Metal Kick Plate, 10" X 34"

The Rockwood K1050 is the standard-duty metal kick plate from Rockwood Manufacturing, a door protection product line Rockwood has produced since 1946 at its facility in Rockwood, PA. This specific configuration is 10" high by 34" wide in US3 Bright Brass finish, .050" thick with all four edges beveled, and includes 10 mounting holes with #6 x 5/8" SMS fasteners.

The 34" width fits a standard 36" door on the push side. Industry practice and most door hardware specifications call for a kick plate width of door width minus 2" on the push side, and door width minus 1-1/2" on the pull side. A 34" kick plate on a 36" push-side door leaves a 1" reveal on each side, which is the standard specified clearance. For all door protection hardware and builders hardware accessories, browse our full builders hardware catalog.

Why 10" Height Instead of Standard 8"

The standard commercial kick plate height is 8". A 10" kick plate extends the protected zone an additional 2" up the door face, which matters in applications where cart traffic, wheelchair footrests, or equipment movement regularly contacts the door above the standard 8" level. Hospitals, food service facilities, institutional kitchens, and school corridors with heavy cart traffic are all applications where the 10" height is specified over 8" for additional coverage. If foot traffic is the primary concern and cart or equipment contact is not a factor, an 8" plate covers the impact zone adequately. For applications with high cart or equipment impact, 10" provides meaningful additional protection without moving into armor plate territory.

Rockwood K1050-10x34-US3 Technical Specifications

Series: Rockwood K1050, Standard Duty. Height: 10" (254mm). Width: 34" (864mm). Thickness: .050" (1.27mm), beveled all 4 sides. Material: Brass. Finish: US3 Bright Brass. Fasteners: #6 x 5/8" OH SMS, included. Mounting holes: 10. Fire rating: UL Listed for 90-minute label wood doors and 3-hour label metal doors. NFPA 80 compliance: Meets NFPA 80 Standards 2-4.5 (Protection Plates); labeling not required where top of plate is not more than 16" from bottom of door. Door width compatibility: Fits 36" door push side (34" = 36" minus 2"); for 36" pull side, use 34.5" (36" minus 1-1/2"). Manufacturer: Rockwood Manufacturing Company, ASSA ABLOY brand, founded 1946, Rockwood PA.

US3 Bright Brass Finish

US3 is the BHMA designation for Bright Brass, a polished brass finish with a clear lacquer topcoat that slows natural oxidation and maintains the bright reflective appearance over time. It coordinates with other US3 hardware finishes across lever locks, hinges, door closers, and exit device trim. US3 is the standard specification for traditional commercial and institutional aesthetics where a warm, polished metal tone is required.

K1050 Series Duty Levels

The Rockwood K1050 is the standard-duty option in the kick plate lineup. The K1038 is the economy version at .038" thickness for lighter-duty applications. The K1062 is the heavy-duty version at .062" thickness for high-abuse environments, loading docks, and institutional applications where standard duty degrades faster than the renovation cycle. For most commercial and light institutional applications, the K1050 at .050" is the correct specification. For correctional, behavioral health, or heavy industrial applications, specify the K1062. For additional door control accessories, browse our door stops and holders catalog.
