About this item
The PRT03 is the rectangular pull handle outside trim for Dormakaba exit devices. There's no cylinder, no lever, and no key function. The outside trim provides a stainless steel D-pull handle on a 3-inch plate for outside access when the device is in the dogged position. When the exit device is dogged open (pushpad held down, latch released for free-passage periods), this pull handle is the only hardware visible and functional from the outside of the door. It gives occupants approaching from outside a clean, robust grip surface without giving them any control over the latch or the device from the corridor.
The PRT03 is the Grade 1, projecting rectangular pull configuration. It's specified alongside Dormakaba 9000 Series and 8000 Series exit devices on doors where outside key-controlled entry isn't required on that specific opening and visual symmetry with the inside device is the specification priority. For all Dormakaba exit device trims, browse our Dormakaba exit device trims catalog. For all commercial exit hardware, view our exit hardware catalog.
PRT03 vs. PRT02: Two Pull Handle Configurations
Both the PRT02 and PRT03 are rectangular pull handle trims for Dormakaba exit devices. Both use finish 630 Satin Stainless Steel. Both are pull-only with no key function.
The PRT02 is the 3-inch wide flat plate trim: a flush, thin-profile rectangular plate with a minimal pull grip. It's the lower-profile option when the architectural specification calls for pull-only hardware that recedes from the door surface.
The PRT03 (this product) is the 3-inch plate with a projecting rectangular pull handle. The handle projects further from the door face, providing a deeper grip surface. It's the Grade 1 version: more robust construction, more substantial projection, and more ergonomic for high-frequency use on busy building entrances. For openings where aesthetics require minimal projection, the PRT02 is the choice. For Grade 1 performance with a more graspable pull, the PRT03 is the correct specification.
Dormakaba PRT03 630 Technical Specifications
SKU: PRT03D630. Also known as: Dorma PRT03, PRT03-630, PRT03 D 630, Dormakaba 9000 pull handle trim. Product type: Outside exit device trim, pull handle only. Pull style: Rectangular D-pull. Plate width: 3 inches. Handle projection: Projecting (deeper than PRT02 flat plate). Function: Pull only, no key, no cylinder. Grade: 1. Finish: 630 Satin Stainless Steel (US32D). Compatible exit devices: Dormakaba 9000 Series (9100, 9300, 9400, 9600, 9700, 9800), Dormakaba 8000 Series (8300, 8400); verify specific series compatibility at time of order. Application: Outside pull when device is dogged; no access control function.
When to Specify Pull-Only Trim
Pull-only outside trim is the correct specification when outside entry control at that door is handled by a separate access point. In a building where the main entrance has an access-controlled electric strike or keypad, secondary exit-only doors that require outside re-entry don't always need full cylinder trim. If occupants who need to re-enter from outside all have main entrance access, the secondary exit device with a pull-only trim keeps hardware costs down and simplifies the door schedule without creating an access control gap.
