Corbin Russwin L9/N9 Lever Trim for ED5200/ED5400 Exit Device

The Corbin Russwin L9/N9 lever trim is the lever-style outside trim assembly for the Corbin Russwin ED5200, ED5400, and ED5800 exit device platforms, configurable across 10 part numbers covering 5 ANSI functions in 2 lever style families. The naming convention is straightforward: "N" prefix is Newport lever style; "L" prefix is Lustra lever style; the three-digit suffix identifies function (955 classroom, 957 nightlatch, 959 storeroom, 910 passage, 950 dummy); "ET" indicates exit trim. Models available in order: N955ET, L955ET, N957ET, L957ET, N959ET, L959ET, N910ET, L910ET, N950ET, L950ET. Lever trim is handed (specify RHR or LHR). Uses a rim cylinder (sold separately, see Corbin Russwin Rim Cylinders for compatible options). ADA compliant for accessible commercial openings. SKU L955ET. In stock under Corbin Russwin Exit Device Trims within Exit Device Trims and Mullions in Exit Hardware.

Which Exit Device Does This Fit

The L9/N9 trim mounts on three Corbin Russwin ED5000 series exit device chassis: ED5200 rim exit device (single-door perimeter and high-traffic openings), ED5400 surface vertical rod (double-door applications without a center mullion), and ED5800 concealed vertical rod (double-door applications with concealed rods inside the door for clean aesthetics on glass and storefront installations). For mortise exit devices in the same ED5000 platform, see the matching Corbin Russwin N9M Mortise Trim which fits the ED5600 mortise chassis. The trim is not interchangeable across exit device platforms; verify the exit device model on your existing installation or specification before ordering.

Pick the Right Function: 955, 957, 959, 910, or 950

The three-digit suffix identifies which trim function matches your door's use case. 955 Classroom trim has a key-locked outside lever (lever locked from outside, key retracts latch and unlocks lever, push bar always allows free egress). Use for classrooms, offices, and any opening that needs keyed outside entry with always-free inside egress. 957 Nightlatch trim has a key-only outside operation (no lever; key retracts the latch when needed; push bar always allows free egress). Use for back-of-house, service entries, and any opening that needs key-only outside access with no lever appearance. 959 Storeroom trim has a fixed outside lever with key access (lever always rigid from outside, key retracts latch, push bar always allows free egress). Use for storerooms, supply closets, IT rooms, and any opening where outside entry should always require a key. 910 Passage trim has a free outside lever (no key, no locking, lever retracts latch from either side). Use for unlocked corridor and passage doors that need a code-compliant exit device for fire and life-safety. 950 Dummy trim is non-functional cosmetic trim for the inactive leaf of double doors that don't need outside operation. Use on the inactive leaf of pairs.

Newport vs Lustra Lever Style

The "N" and "L" prefixes select between Corbin Russwin's two lever style families. Newport (N) is the traditional curved lever profile with a slight wave, common in healthcare, education, and government specifications where the visual matches existing Corbin Russwin lever trim throughout the building. Lustra (L) is the contemporary straight lever profile with cleaner lines, common in newer commercial construction and corporate office specifications. Both lever styles meet the same ADA compliance requirements and use the same chassis hardware. The choice is purely visual.

Specifications

Function: 5 options (955 classroom, 957 nightlatch, 959 storeroom, 910 passage, 950 dummy). Lever style: Newport (N) curved or Lustra (L) straight. Compatible exit devices: Corbin Russwin ED5200 rim, ED5400 surface vertical rod, ED5800 concealed vertical rod. Cylinder: uses standard rim cylinder (cylinder not included; ordered separately). Handing: lever trim is handed; specify RHR (right hand reverse) or LHR (left hand reverse). Compliance: ADA Americans with Disabilities Act compliant for accessible commercial openings.

Finish Options

Six finishes available at order: 605 (US3) Bright Brass, 612 (US10) Satin Bronze, 613 (US10B) Oil Rubbed Bronze, 626 (US26D) Satin Chrome, 630 (US32D) Satin Stainless Steel, and 722 Black Oxidized Bronze. 630 satin stainless and 626 satin chrome are the most-specified finishes for healthcare, education, and government projects. 613 oil rubbed bronze and 722 black oxidized bronze are common in hospitality and high-end commercial specifications.

Required Accessories

The L9/N9 trim ships without cylinder. Order one of the following matching Corbin Russwin rim cylinders to complete the installation: Corbin Russwin 3000-200 Rim Cylinder 6-pin for conventional keying, Corbin Russwin 3070-178 Rim IC Cylinder Housing paired with the Corbin Russwin 8000 Interchangeable Core 6-pin for facilities running an LFIC keying system. The dummy 950 function does not require a cylinder.

Related Trims for the Same Exit Devices

For thumbpiece and pull alternatives on the same ED5200/ED5400/ED5800 chassis, see Corbin Russwin TH9 Thumbpiece Trim, Corbin Russwin P9 Pull Trim, and Corbin Russwin A9/C9/PR9 Lever Trim for alternate lever style families. For electrified trim with fail-safe or fail-secure access control, see Corbin Russwin A9903 Electrified Lever Fail-Safe, Corbin Russwin A9905 Electrified Lever Fail-Secure, Corbin Russwin N9903ET Electrified Newport Lever Fail-Safe, and Corbin Russwin N9905ET Electrified Newport Lever Fail-Secure.
