Backset:2-3/4 Inch"
Door Thickness:1-3/4" standard;
Handing:Non-handed
Key Override:Marks "C" keyway, 6 pin w/2 keys,
Lock Body:Cylindrical "Survivor" featuring the "Clutch" for trouble free service
Latch:Grade 2, 2-3/4" backset, 1/2" throw, 3 Hour UL fire rating
Strike Plate:4-7/8" ASA strike
Cylinder Type:Conventional Cylinder
Finish:19 With 26D Levers
Finish Description:Split Finish
Function:Electronic Keypad
Grade:ANSI/BHMA Grade 2
Keyblank Grouping:SCHL-C-6-1
Keying Charges:CCAM
Keyway:Marks C
Product Type:Access Control
Series:I-QWIK Series
Strike:ANSI, 1-1/4" x 4-7/8", 1-1/4" Lip, Square Corner
