Stanley BEST 7T-3-7-L-STK-612 Grade 2 Cylinder/Blank Deadbolt - 2-3/4 Backset - Satin Bronze
Product Details
Stanley BEST 7T-3-7-L-STK-626 Grade 2 Cylinder/Blank Deadbolt - 2-3/4 Backset - Satin Chrome
Deadbolt Operated by:Turning the key in the outside cylinder - inside cylinder is blank.
Function & Diag. ANSI (Fed. No.):E2161, E2162 (181L)
Core Housing: 7 pin housingaccepts all Best cores
Deadbolt: 1" throw, 5 ⁄8" x 7 ⁄8" bolt. Brass nickel plated, with concealed hardened steel free-turning pin. Housing fits 1" bore.
Door thickness: Fits 1 3⁄4" doors (standard)
Faceplate:1 1/8" x 2 1⁄4" brass or bronze base material.
Strike:8TSTK – Rectangular 1 1⁄8" x 2 3⁄4" (ANSI A156.36-2010)
Warranties:Three-year mechanical Three-year finish (613 carries no finish warranty)
Certifications
ANSI/BHMA A156.36-2010 Auxiliary Locks, Grade 2 with ICD series Core and 8STK Strike – 7T Series
UL/cUL listed for use as auxiliary lock type on 3-hour fire doors
ANSI/ICC A117.1 Accessible and Usable Building and Facilities (ADA) section
404.2.6 compliant
