Alarm Lock Trilogy DL2800IC 26D Audit Trail Lock, Accepts IC Core (Best)- Satin Chrome (Special Price)

Product Details

Trilogy DL2800IC 26D Digital Battery operated*Lock, Audit Trail, Accepts IC*Interchangeable Core Best, Arrow, KSP, Medeco Keymark & Kaba Peaks - Satin Chrome

Interchangeable Core Models: Accepts 6 & 7 Pin Cylinders from: Best, Arrow, KSP, Medeco Keymark & Kaba Peaks. Also available IC Core models for Yale, Medeco, Sargent, Corbin/Russwin CL and Schlage. Alarm Lock Tailpiece is supplied; IC Core is not included.

Alarm Lock -Trilogy*DL2800IC Series:*

Rugged clutch mechanism and Grade 1 durability ensure long life

200 user codes including: Master, manager, supervisor and basic user. Also one-time entry service code

150 scheduled events, including 4quick schedulesfor programming the 4 most common time schedules in one step

1000 event audit trail with time/date stamp for a printable record of door access activity by user, can be polled with the (AL-PCI)Interface Cable & Sofware(sold separately)to any PC using DLWindows Software.Activities included are: unlock/lock events, program mode changes, user entry, keypad lockout, remote release events, unauthorized code attempts, etc

Hand-held infrared(AL-IR1) printer can be used to print on-site from the lock(sold separately).

Data Transfer Module (AL-DTMII)can also beused to transfer program data from the PC (running DL-WINDOWS software) to the lock and receives audit trail from the lock. Can store data for up to 96 locks at a time(sold separately).

Weatherproof performance, water-sealed for use inside and out, with operational temperature range of +151F to -31F (+66C to -35C)

Entry allowance from 5-15 seconds

Greater security withtemporary keypad lockoutafter 3 unsuccessful code-entry attempts

Real time clock allows logging of events to within 1 second of accuracy

Programmable relays energize when one or more selected events occur

4 time-out functions allow a user to enable other users or unlock the lock for some time period without needing to return to the lock

Battery operated; Uses 5 AA alkaline batteries, supplied. Audible low battery alert, visual and audible entry indicators, unique Flex Drivemotor. 100,000 cycles typical.

Available in standard Trilogy leverset (straight) or with Regal (curved) leverDL2875IC

Door Thickness:1 5/8" to 1 7/8." Other thicknesses. Please consult factory.

Backset:2 3/4" Standard. 2 3/8" backset also available.

Interchangeable Core Models: Accepts 6 & 7 Pin Cylinders from: Best, Arrow, KSP, Medeco Keymark & Kaba Peaks. Also available IC Core models for Yale, Medeco, Sargent, Corbin/Russwin CL and Schlage. Alarm Lock Tailpiece is supplied; IC Core is not included.

Latchbolt:UL Listed, fire rated, 3 hours, 1/2" throw, solid brass, deadlocking. Reversible. Adjustable front for flat or beveled doors.

Strike:1 1/8" x 2 3/4" T strike & 1 1/4"  x 4 7/8" ASA strike included. With screws for wood or metal jambs.

Latch Front:1 1/8" x 2 1/4" wrought brass or stainless steel.

Handing:Non-handed.

Models:Alarm Lock,Trilogy, DL2800IC26D, DL2800IC , DL2800IC-C , DL2800IC-M DL2800IC-R  US26D, DL2800IC-Y DL2800IC-S US26D, DL2800ICS , DL2800ICC , DL2800ICM, DL2800ICR, DL2800ICY, Finishes: Satin Chrome

Alarm Lock Trilogy DL2800IC 26D Audit Trail Lock, Accepts IC Core (Best)- Satin Chrome (Special Price)

SKU: DL2800ICUS26D

In Stock

Backset *

2-3/4" Backset
2-3/4" Backset
2-3/8" Backset
2-3/8" Backset

$777.87

$1,234.72

You saved $456.85

About this item

Economy audit trail pushbutton lock Standalone access control systems with audit trail feature for indoor and outdoor applications.

Trilogy DL2800IC 26D Digital Battery operated*Lock, Audit Trail, Accepts IC*Interchangeable Core Best, Arrow, KSP, Medeco Keymark & Kaba Peaks - Satin Chrome

Interchangeable Core Models: Accepts 6 & 7 Pin Cylinders from: Best, Arrow, KSP, Medeco Keymark & Kaba Peaks. Also available IC Core models for Yale, Medeco, Sargent, Corbin/Russwin CL and Schlage. Alarm Lock Tailpiece is supplied; IC Core is not included.

Alarm Lock -Trilogy*DL2800IC Series:*

Rugged clutch mechanism and Grade 1 durability ensure long life

200 user codes including: Master, manager, supervisor and basic user. Also one-time entry service code

150 scheduled events, including 4quick schedulesfor programming the 4 most common time schedules in one step

1000 event audit trail with time/date stamp for a printable record of door access activity by user, can be polled with the (AL-PCI)Interface Cable & Sofware(sold separately)to any PC using DLWindows Software.Activities included are: unlock/lock events, program mode changes, user entry, keypad lockout, remote release events, unauthorized code attempts, etc

Hand-held infrared(AL-IR1) printer can be used to print on-site from the lock(sold separately).

Data Transfer Module (AL-DTMII)can also beused to transfer program data from the PC (running DL-WINDOWS software) to the lock and receives audit trail from the lock. Can store data for up to 96 locks at a time(sold separately).

Weatherproof performance, water-sealed for use inside and out, with operational temperature range of +151F to -31F (+66C to -35C)

Entry allowance from 5-15 seconds

Greater security withtemporary keypad lockoutafter 3 unsuccessful code-entry attempts

Real time clock allows logging of events to within 1 second of accuracy

Programmable relays energize when one or more selected events occur

4 time-out functions allow a user to enable other users or unlock the lock for some time period without needing to return to the lock

Battery operated; Uses 5 AA alkaline batteries, supplied. Audible low battery alert, visual and audible entry indicators, unique Flex Drivemotor. 100,000 cycles typical.

Available in standard Trilogy leverset (straight) or with Regal (curved) leverDL2875IC

Door Thickness:1 5/8" to 1 7/8." Other thicknesses. Please consult factory.

Backset:2 3/4" Standard. 2 3/8" backset also available.

Interchangeable Core Models: Accepts 6 & 7 Pin Cylinders from: Best, Arrow, KSP, Medeco Keymark & Kaba Peaks. Also available IC Core models for Yale, Medeco, Sargent, Corbin/Russwin CL and Schlage. Alarm Lock Tailpiece is supplied; IC Core is not included.

Latchbolt:UL Listed, fire rated, 3 hours, 1/2" throw, solid brass, deadlocking. Reversible. Adjustable front for flat or beveled doors.

Strike:1 1/8" x 2 3/4" T strike & 1 1/4"  x 4 7/8" ASA strike included. With screws for wood or metal jambs.

Latch Front:1 1/8" x 2 1/4" wrought brass or stainless steel.

Handing:Non-handed.

Models:Alarm Lock,Trilogy, DL2800IC26D, DL2800IC , DL2800IC-C , DL2800IC-M DL2800IC-R  US26D, DL2800IC-Y DL2800IC-S US26D, DL2800ICS , DL2800ICC , DL2800ICM, DL2800ICR, DL2800ICY, Finishes: Satin Chrome

Alarm_Lock_DL2800_IC
Alarm Lock Trilogy DL2800IC 26D Audit Trail Lock, Accepts IC Core (Best)- Satin Chrome (Special Price)

Product code: DL2800ICUS26D

In Stock

$1,234.72

$777.87

Keypad:Rugged, vandal-resistant, all metal, 12 button programmable for multi-level access functions including group or individual user codes, master and management codes, passage and emergency or service code, lockout and remote override capability and allowable entry time from 5 to 15 seconds.

Operation:Durable clutch mechanism permits turning lever without retracting latch and reduces stress on lock bodies and spindle. Outside lever free turning in locked position. Entering access code, key bypass, or remote bypass will allow lever to retract latch. Inside lever always instant egress.

Door Prep:Standard ANSI A115 Series Prep, modified by adding additional through-bolt holes.

Compliances:Grade I, heavy duty cylindrical lockset, UL listed to the 10C Positive Pressure Specification and FCC certified.

ADAcompliant levers.
