Nortek - LInear 212R Indoor / Outdoor Surface-mount Ruggedized Keypad

Nortek - LInear 212R Indoor / Outdoor Surface-mount Ruggedized Keypad 120 users

212RThe ruggedized R style 212R keypad features a cast aluminum housing and all-metal faceplate that has been treated with polyurethane to increase its protection from corrosion.

The ruggedized uses an all metal Braille, alpha-numeric keys. There is also an internal sounder that is used to indicate key press feedback.

The Ruggedized's housing can be mounted to a variety of surfaces. Suggested mounting includes; gate goosenecks, post,concrete walls, etc.

Additional tamper resistance is provided with the onboard tamper loop that can be used to indicate the removal of the faceplate.

*Features * 120 users Indoor/outdoor weather resistant, self-contained metal housing Surface mount vandal resistant design One piece housing suitable for wall, post, or gooseneck mounting Durable metal Braille alpha-numeric keys 4 onboard programmable timed relays Functionality mode: 212, 232

Specifications * *Current draw:108 mA maximum (add 30 mA for each additional relay)

Operating voltage:12-24 VAC/DC - auto adjusting

Dimensions:3.75″ W x 5.25″ H x 2.50″ D

Temperature tolerance:-20F to 130F

Order number 0-211466,  0-211466, nortek 212r, linear 212r, nortek linear 212r, 212r nortek, 212r nortek linear, 212r linear,
