PDQ 9300-689 8' Mullion, Key Removable

PDQ 9300-689 Mullion, 8', Key Removable

The PDQ 9300 Series removable mullions are designed for use with the 6300/6400 Series Rim Exit Devices on pairs of doors. They are designed for quick removal from the top bracket by simple operation of the rim cylinder when a clear, unobstructed large opening is required. Once the mullion is removed, carts, gurneys, large machinery and the like can freely pass through the opening. When the mullion is re-installed, the unit will self lock in place without a key.

9300-689:Mullion, 8' non-fire rated and under opening height (can be cut down to non standard opening height).

Specifications:

9300 Mullions SERIES Mullion Head/Foot brackets:  Cast Stainless Steel Tube.Dimensions:

  Powder Coated 2" x 3" Steel - 3/16" Wall.

Strike:

   - 639080 Strike included for Fire Labeled.

   - Strike not included for panic mullion. Use supplied strike with exit device.

Size:8' or 10' lengths - Can easily be cut to shorter size in field. Finish:   Powder Coated 689 (Aluminum) - can be painted.

Electrified Options:  Wire routing w/ plugs.

Warranty:  One (1) year limited warranty. Certifications: Compliances: Listings:

   - Fire model is 3 hour fire labeled for pairs up to and including 8' x 8' (With 6300RF/6400RF Rim Device). Fire Rated mullion listed only when used with PDQ's 6300/6400 Fire Rated Devices. Use with any other device will void UL Fire Rating.

   - Meets requirements of the BAA as a COTS product manufactured in the United States.

Model: PDQ 9300, PDQ 9300-689, 9300, 9300 689
