SDC 260HV Conventional Mortise Electric Bolt Lock With Auto Relock Switch, Failsecure - Aluminum

SDC 260HV Conventional Mortise Electric Bolt Lock *With Auto Relock Switch, Failsecure -  Aluminum*

Failsecure4-7/8" H x 1-1/4" W faceplate with auto relock switch

The failsecure 260 bolt locks are equipped with an auto relock switch that keeps the bolt retracted when the door is open and causes the door to lock when closed. The auto relock switch and the bolt assembly are both adjustable for wide door gaps. Not for use in wood frames.

Electrical Specifications:

Voltage: Dual 900/450 mA @ 12/24 VDC

Mechanical Specifications:

Finish: 628 Anodized Aluminum

Faceplate:  4-7/8" H x 1-1/4" W x 0.25" D

Strike: Mortise strike standard. Not for wood frames.

Bolt: 1/2" dia. x 1/2" throw

Depth: 5"

Application:

 Pharmacy Cabinets  Gun Cabinets

 Utility Cabinets        Display Cabinets

 OEM Applications     Swing and Sliding Doors
