Product Details
Stanley DAP-3 US26D Double Acting Pivot - Satin Chrome
DAP-3(ANSI A2742) Brass and mallable iron standard finishes
Heavy duty pivot assembly for commercial double acting interior doors of average frequency use, weighing up to 135 lbs. (61 Kg) and not exceeding 3' (91mm) in width
For 1-3/8" (35 mm) and 1-3/4" (44mm) thick doors
Header plate has a walking beam design to simplify door installation
Extra heavy 1/4" (6.35mm) thick solid brass frame plates
Oil impregnated bronze bearing in top door plate
Smooth acting ball bearing assembly in bottom door plate
For door undercuts in 1/16" (1.6mm) increments from 3/4" (19mm) to 1" (25mm)
Bottom bracket is frame mounted and must be floor supported
The recommended positioning of the door is to inset it 1/8" (3.2 mm) from the bathroom face of the frame
Specifications:Pivot point 1-1/4" (31.8mm) from jamb Header plate (brass) 4-7/8" x 7/8" x 1/4" (124mm x 22mm x 6.4mm)
Top door plate(malleable iron) 4-3/8" x 1" x 1/4" (111mm x 25.4mm x 6.4mm)
Bottom jamb bracket(brass) 3" x 1-1/4" x 1/4" (76mm x 32mm x 6.4mm)
Bottom door plate(malleable iron)............4-3/8" x 1" x 1/4" (111mm x 25.4mm x 6.4mm)
Flat Head Screws Per Set: 414 x 1-1/2 wood screws,51/4'20 x 1/2 machine screws
Model:Stanley DAP3US26D, DAP326D
