Roton 780-157 83" Full Surface Continuous Hinge, Narrow Frame,Roton 780-157 83" Full Surface Continuous Hinge, Narrow Frame

Full Surface - Narrow or Inset Frame for Retrofit Application  - Swing Clear Action -For Doors of any Material -Standard Duty for medium frequency doors

Hinge Length:83" (210.8 cm)Door Screws:19

Jamb Screws:19

Clearance:

1/32" (1 mm) minimum recommended for hinge side plus standard lockside clearanceFasteners:Dril-Kwik

screws and Sex boltsLength Options:Standard and Custom

Door Reinforcement:None required

Frame Reinforcement:None required to 200 lbs. Heavier weight use 16 gauge channel

Special Features:

For surface applications where frame face dimension is limited

Security moldings

1/16" (1.5 mm) inset
