Securitron UNL-12 Electromechanical Maglock - UnLatch For Cylindrical Locks - 12VDC

Product Details

Securitron UNL-12 Electromechanical Maglock - UnLatch For Cylindrical Locks - 12VDC

Features: No cutting or altering of the jamb required Fits standard ANSI 4-7/8" strike cutout Also available in Polished Brass (US03) and Oil Rubbed Bronze (US10B) Motorized, no solenoids Fully concealed installation Maintains deadlatch function at all times Continuous duty Releases under pre-load Support deadlatch function Latch status sensor is standard (SPDT) MagnaCare Lifetime Replacement No Fault Warranty UL Listed

Current Draw and Voltage: 12VDC: 40mA continuous, minimum 300mA when operating 24VDC: 40mA continuous, minimum 200mA when operating Higher capacity supply (1-3 Amps) is recommended for startup in rush to achieve best operation under pre-load

Operating Temperature:-20 to +125F [-29 to +52C]

Shipping Weight:1.6 lbs.

Finishes:US03/605 - Polished Brass, US26D/626 - Stainless Steel, US10B/613 - Oil Rubbed Bronze

Model:UNL12, UNL12605, UNL12613, UNL12626

Securitron UNL-12 Electromechanical Maglock - UnLatch For Cylindrical Locks - 12VDC

SKU: UNL12

In Stock

Finish *

626 - Satin Chrome
626 - Satin Chrome
613 - Oil Rubbed Bronze [+$32.76]
613 - Oil Rubbed Bronze [+$32.76]

$442.08

About this item

UnLatch is for any application where an electric strike would be used for a cylindrical/tubular lockset. UNL requires three wires for operation - continuous positive DC, continuous negative DC, and a trigger input to unlock.UnLatch supports full dead latch function, releases under pressure and includes a latch status monitoring output.

Resources

Securitron UNL-12 Electromechanical Maglock - UnLatch For Cylindrical Locks - 12VDC

Features: No cutting or altering of the jamb required Fits standard ANSI 4-7/8" strike cutout Also available in Polished Brass (US03) and Oil Rubbed Bronze (US10B) Motorized, no solenoids Fully concealed installation Maintains deadlatch function at all times Continuous duty Releases under pre-load Support deadlatch function Latch status sensor is standard (SPDT) MagnaCare Lifetime Replacement No Fault Warranty UL Listed

Current Draw and Voltage: 12VDC: 40mA continuous, minimum 300mA when operating 24VDC: 40mA continuous, minimum 200mA when operating Higher capacity supply (1-3 Amps) is recommended for startup in rush to achieve best operation under pre-load

Operating Temperature:-20 to +125F [-29 to +52C]

Shipping Weight:1.6 lbs.

Finishes:US03/605 - Polished Brass, US26D/626 - Stainless Steel, US10B/613 - Oil Rubbed Bronze

Model:UNL12, UNL12605, UNL12613, UNL12626

1-UNL-12
Securitron UNL-12 Electromechanical Maglock - UnLatch For Cylindrical Locks - 12VDC

Product code: UNL12

In Stock

$614.00

$442.08

UL 10C Listed, 3 hour single door CAN4-S104-80m Listed, 3 hour single door UL Listed to ANSI/SDI-BHMA A250.13(60 PSI) Windstorm ANSI/BHMA A156.31, Grade 1; E09321, E09322, E09323 NFPA - 252 fire door complaint ASTM - E152 fire door complaint Patent Numbers: 5,474,342; 6,022,056

1-UNL-12
Securitron UNL-12 Electromechanical Maglock - UnLatch For Cylindrical Locks - 12VDC

Product code: UNL12

In Stock

$614.00

$442.08
