Cal-Royal ICXP03 Grade 2, Classroom Lock - Accepts SFIC Core

Cal-Royal ICXP03 Grade 2, Classroom Lock - Accepts Small-format Interchangeable Core (SFIC) (core not included)

Dead locking latch bolt operated by lever from either side except when outside lever is locked from outside by key. When outside lever is locked, latch bolt is operated by turning inside lever.

Fits all Major Manufacturers Thru Bolt Locations.

Door Range- 1-3/8" to 2" thickness doors.

Backset- 2-3/4" Standard, 2-3/8", 3-3/4" and 5" optional.

Front- 2-1/4" x 1 1/8", adjustable for flat or beveled doors 1/8" in 2".

Strike- ASA strike standard, "T" and full lip strike available.

Latchbolt- 1/2" Throw solid brass, reversible for RH or LH applications. UL listed. Latch and Stick Screws - 8-32 X 1" FPH dual purpose.

Interchangeable core locks will accept compatible 6 or 7 pin cores with BEST, FALCON and ARROW.

Keys:2 keys per lock.

model:Cal-Royal ICXP03,Cal-Royal ICXP03US26D,Cal-Royal ICXP03US10B,Cal-Royal ICXP03US26,Cal-Royal ICXP03US4,Cal-Royal ICXP03US3,

ANSIStandards - Meets or exceeds requirements of BHMA/ANSI A156.2 Series 4000, grade 2(FF-H 106C), 400,000 cycles.

Exposed Trim- Wrought brass, bronze or stainless steel, levers are Zinc casting, plated to match trim finish.
