LCN 4040XP EDA MC, Door Closer - Metal Cover

4040XP-EDA 689
1-Page36-LCN4000
1-Page41-LCN4000
1-Page42-LCN4000
4040XP-EDA 689
1-Page36-LCN4000
1-Page41-LCN4000
1-Page42-LCN4000
naxt
prev

Product Details

LCN 4040XP EDA MC,- Heavy Duty Door Closer, Extra Duty Arm - Metal Cover

Finish: Powder Coat -ALUM - ALUMINUM (BHMA 689)

Closer Mounting: Parallel Arm (PUSH SIDE) mounting.

LCN 4040XP: 44% increased bearing load capacity - Strongest pinion ever- at 3/4 journal diameter  - Widest bearing ever- at 5/8- Stronger pinion teeth - New V-shieldseal with 20% longer life - XP = eXtra Protection in real world applications - Cast Iron - Forged Steel Arm - Double Heat Treated Steel Pinion - All Weather Fluid - LCN FastPower Adjust - Fast & Accurate Installation.

Power size: 4040XP cylinders are adjustable from size 1 through size 6 and is shipped set to size 3.

Handing: Handed

UL: UL & cUL Listed

ANSI: Tested and certified under ANSI Standard A156.4, grade 1

Arm: EXTRA DUTY ARM, 4040-3077EDA Non-handed parallel arm features forged, solid steel main and forearm for potentially abusive installations.

Cover: METAL COVER, 4040-72MC handed cover

Screw Pack: Packed w/TBWMS (Thru Bolts, Wood & Machine Screws)

LCN 4040XP EDA MC, Door Closer - Metal Cover

SKU: 4040XPEDAMC

In Stock
Picture for manufacturer LCN
icon Chat

$491.26

Finish *

ALUM - ALUMINUM (BHMA 689)
ALUM - ALUMINUM (BHMA 689)

Handing *

About this item

The new 4040XP is LCN's most durable heavy duty closer designed for the most demanding, high use and abuse applications.

Resources

LCN 4040XP EDA MC,- Heavy Duty Door Closer, Extra Duty Arm - Metal Cover

Finish: Powder Coat -ALUM - ALUMINUM (BHMA 689)

Closer Mounting: Parallel Arm (PUSH SIDE) mounting.

LCN 4040XP: 44% increased bearing load capacity - Strongest pinion ever- at 3/4 journal diameter  - Widest bearing ever- at 5/8- Stronger pinion teeth - New V-shieldseal with 20% longer life - XP = eXtra Protection in real world applications - Cast Iron - Forged Steel Arm - Double Heat Treated Steel Pinion - All Weather Fluid - LCN FastPower Adjust - Fast & Accurate Installation.

Power size: 4040XP cylinders are adjustable from size 1 through size 6 and is shipped set to size 3.

Handing: Handed

UL: UL & cUL Listed

ANSI: Tested and certified under ANSI Standard A156.4, grade 1

Arm: EXTRA DUTY ARM, 4040-3077EDA Non-handed parallel arm features forged, solid steel main and forearm for potentially abusive installations.

Cover: METAL COVER, 4040-72MC handed cover

Screw Pack: Packed w/TBWMS (Thru Bolts, Wood & Machine Screws)

4040XP-EDA 689
LCN 4040XP EDA MC, Door Closer - Metal Cover

Product code: 4040XPEDAMC

In Stock

$491.26

$491.26

4040XP-EDA 689
LCN 4040XP EDA MC, Door Closer - Metal Cover

Product code: 4040XPEDAMC

In Stock

$491.26

$491.26
